Ecolink IP65 Floodlight 10W 4000K With Sensor
Part Number:
2501598891
MPN:
911401854585
- Product Type:
- Residential Floodlights
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
Outdoor LED floodlights suitable for a wide range of applications such as lighting façades, commercial or industrial areas, car parks, etc.
- · Energy efficiency
- · Motion detection
- · Easy installation
- · Durability
- · Weatherproof
- · Saves money on energy bills
Technical Specifications
Technical Specifications
Downlight / spot luminaire / floodlight | |
| Impact resistance (IK rating) | IK06 |
|---|---|
| Housing colour | Black |
| Lamp cap/base | E10 |
| Degree of protection (IP), front side | IP65 |
| Housing material | Aluminium |
| Conductor cross section | 1 mm² |
| Width | 137 mm |
| Number of poles | 3 |
| Length | 107 mm |
| Height/depth | 58 mm |
| Rated life time L70/B50 at 25 °C | 35000 h |
| Flickering value Pst LM | 1 |
| Max. number of luminaires per miniature circuit breaker C16 | 256 |
| Max. number of luminaires per miniature circuit breaker B16 | 218 |
| Maximum system power | 10 W |
| Power factor | 0.9 |
| Failure rate at median useful life of 35,000 hrs at 25 °C ambient (tq) | 7.5 % |
| Lumen maintenance (35,000 h at 25 °C) | 65 % |
| Colour temperature | 4000 - 4000 K |
| Nominal voltage | 220 - 240 V |
| Connectable conductor cross section | 1 - 1 mm² |
| Nominal current | 45 - 41 mA |
| Rated ambient temperature acc. IEC62722-2-1 | 25 - 25 °C |
| Rated luminous flux according to IEC 62722-2- 1 | 850 - 850 lm |
| Suitable for suspended mounting | No |
| With light sensor | No |
| With movement sensor | Yes |
| Suitable for wall mounting | Yes |
| Constant luminous flux control | No |
| Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24 | No |
| Suitable for traverse mounting | No |
| Suitable for surface mounting | Yes |
| Suitable for clamp-mounting | No |
| Control gear included | Yes |
| Suitable for recessed mounting | No |
|---|---|
| Light source included | Yes |
| Replaceable control gear | No |
| Dimming 0-10 V | No |
| Dimming Zigbee | No |
| Dimming 1-10 V | No |
| Dimming leading edge | No |
| Dimming with push-button | No |
| Dimming sine wave reduction | No |
| Compatible with Google Assistant | No |
| Dimming touch and dim | No |
| Luminaire may be covered with thermally insulating material | No |
| Suitable for light-track mounting | No |
| Suitable for pedestal/floor mounting | Yes |
| Suitable for ceiling mounting | No |
| Fit for workplace acc. EN 12464-1 | No |
| Brushed surface | No |
| IFTTT support available | No |
| Dimming mains voltage modulation | No |
| Dimming potentiometer (integrated) | No |
| Dimming programmable | No |
| Dimming trailing edge | No |
| Compatible with Amazon Alexa | No |
| Dimming RF | No |
| Dimming DALI-2 | No |
| Dimming DALI | No |
| Bluetooth operated | No |
| Compatible with Apple HomeKit | No |
| Dimming DMX | No |
| Dimming DSI | No |
| Dimming manufacturer's proprietary system | No |
| Dimming LineSwitch | No |
| Suitable for low voltage cable system | No |
