OSRAM DULUX® L LED HF & AC MAINS 18 W/4000K
Part Number:
2501127641
MPN:
4058075822153
- Product Type:
- LED CFL Retrofit Lamps
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
LED replacement for conventional compact fluorescent lamps for use in ECG luminaires or on AC mains.
- · LED replacement for conventional compact fluorescent lamps for use in ECG luminaires or on AC mains
- · Single-ended four-pin plug-in 2G11 base
- · Type of protection: IP20
- · Type of protection: IP20
- · Lifetime: up to 30,000 h
- · Mercury-free lamps
- · Quick, simple and safe replacement
- · Simple replacement thanks to similar design as conventional compact fluorescent lamps
- · Low energy consumption
- · Operation directly on 230 V AC mains possible
Technical Specifications
Technical Specifications
LED Lamp | |
| Colour of light acc. EN 12464-1 | Neutral 3300-5300 K |
|---|---|
| Colour rendering index (CRI/Ra) | 80-89 |
| Colour consistency (McAdam ellipse) | SDCM6 |
| Cap | 2G11 |
| Colour | White |
| Housing colour | White |
| Energy efficiency class according to EU regulation 2019/2015 | E |
| Photobiological safety according to EN 62471 | RG0 |
| Degree of protection (IP rating) | IP20 |
| Type of glass/cover | Frosted |
| Voltage type | AC |
| Lamp shape | Tube, single-ended |
| Length | 416.5 mm |
| Diameter | 44 mm |
| Luminous intensity | - cd |
| Weighted energy consumption in 1,000 hours | 18 kWh |
| Lamp efficacy | 127 lm/W |
| Min. number of switching cycles | 200000 |
| Rated luminous flux according to IEC 62612 | 2300 lm |
| Power factor | 0.9 |
| Average nominal lifespan | 30000 h |
| Nominal voltage | 220 - 240 V |
| Nominal current | 79 - 79 mA |
|---|---|
| Luminous flux | 2300 - 2300 lm |
| Colour temperature | 4000 - 4000 K |
| Beam angle | 140 - 140 ° |
| Lamp power | 18 - 18 W |
| With movement sensor | No |
| Suitable for electronic ballast | Yes |
| Compatible with Apple HomeKit | No |
| With remote control | No |
| Remote operation possible | No |
| IFTTT support available | Yes |
| Dimming touch and dim | No |
| With twilight switch | No |
| Dimming Zigbee | No |
| Dimming Wi-Fi | No |
| Filament lamp | No |
| Dimming leading edge | No |
| Dimming trailing edge | No |
| Dimming Bluetooth | No |
| Suitable for magnetic ballast | No |
| Compatible with Amazon Alexa | No |
| Compatible with Google Assistant | No |
