VIALOX® NAV®-T SUPER 4Y® 150 W SUPER 4Y
Part Number:
2500098159
MPN:
4050300024400
- Product Type:
- High-Intensity Discharge (HID) Lamps
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Details
Product Details
Osram VIALOX High-pressure sodium vapor lamp for open and enclosed luminaires. This product provides high luminous efficacy, long lifetime, and very good luminous flux maintenance throughout the life of the lamp. Energy savings of up to 50 % when replacing inefficient mercury vapor lamps . Optimum energy efficiency on POWERTRONIC PTo 3DIM ECGs. Dimmable on conventional control gears and electronic control gears. Suitable for use in open and enclosed luminaires such as streets, outdoor lighting, industrial installations. Outdoor applications only in suitable luminaires.
- · Lamp survival factor: 95 % after 16,000 h burning time
- · Average lifetime: up to 36,000 h
- · Service lifetime: 4 years (at approx. 11 h/day)
- · Service lifetime: 4 years (at approx. 11 h/day)
- · ErP compliant according to EU Regulation 245/2009
- · Dimmable on conventional control gears and electronic control gears
- · Long lifetime
- · Very high luminous efficacy
- · Very good luminous flux maintenance throughout the life of the lamp
- · Energy savings of up to 50 % when replacing mercury vapor lamps (HQL)
Technical Specifications
Technical Specifications
High pressure sodium lamp | |
| Energy efficiency class according to EU regulation 2019/2015 | F |
|---|---|
| Lamp designation | T14 |
| Colour rendering index (CRI/Ra) | 20-39 |
| Cap | E40 |
| Lamp shape | Tube, single-ended |
| Lamp power | 150 W |
| Total length | 211 mm |
| Diameter | 47 mm |
| Colour temperature | 2000 K |
| Luminous flux | 17500 lm |
| Weighted energy consumption in 1,000 hours | 162 kWh |
|---|---|
| Lamp efficacy | 116 lm/W |
| Number of discharge tubes | - |
| Average nominal lifespan | 32000 h |
| External ballast required | Yes |
| Mercury-free | No |
| Lighting for plants | No |
| Replacement for mercury vapour lamp | No |
| External ignitor required | Yes |
