25A Trip Curve B RCD Class A Residual Current 30mA 10kA RCBO
Part Number:
2501181648
MPN:
RCBO10-25/30/1MBA
- Product Type:
- Residual Current Devices
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
A fully comprehensive range of 10kA RCBOs, which provides protection for cables, filament lighting circuits, heating loads and domestic applications, as well as protection against earth leakage, overload and short circuits. Lewden 10kA RCBOs are fully compatible with the TP&N range which is the complete solution to managing the distribution of electricity in commercial premises such as offices, warehouses, factories, schools, hospitals etc.
- · Designed and tested for use with Lewden branded distribution boards.
- · Residual current circuit breaker with integral overcurrent protection.
- · Class AC & A.
- · Single module RCBOs are suitable for use in TN-S, TN-C-S, & TT network systems.
Technical Specifications
Technical Specifications
Earth leakage circuit breaker/RCBO | |
| Rated short-circuit breaking capacity according to EN 61009 | 10 kA |
|---|---|
| Rated short-circuit breaking capacity Icn according to EN 61009-1 | - kA |
| Width in number of modular spacings | 1 |
| Number of protected poles | - |
| Rated short-circuit breaking capacity IEC 60947-2 | - kA |
| Current limiting class | - |
| Surge current capacity | - kA |
| Rated fault current | 3 A |
| Rated impulse-withstand voltage (Uimp) | - kV |
| Pollution degree | - |
| Number of poles (total) | 2 |
| Over voltage category | - |
|---|---|
| Rated current | 25 A |
| Rated voltage | 230 V |
| Rated insulation voltage Ui | - V |
| Recess depth | 761 mm |
| Connectable conductor cross section solid-core | - mm² |
| Connectable conductor cross section multi-wired | - mm² |
| Ambient temperature during operating | - °C |
| Concurrently switching N-neutral | No |
| With interlocking device | No |
| Anti-nuisance tripping version | No |
