Homelink Temper & Humidity Environmental Sensor With 10 Yr Subscription
Part Number:
2501665504
MPN:
EI1020_DUP
- Product Type:
- Thermostats & Controls
My Price
£120.76 (exc. VAT) / EA
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Manual
Technical Data Sheet
Product Details
Product Details
Discreet and secure, the Ei1020 Environmental Sensor can be placed throughout a property to monitor temperature and humidity, providing actionable insights to enable the creation of healthier, safer homes.
- · Monitor condensation, damp and mould
- · Easy to install and manage
- · Gather data on indoor environmental conditions
- · Suitable for wall and ceiling mounting
- · Powered by a sealed 10-year lithium battery
- · Connection to Ei1000G SmartLINK Gateway required to extract data
- · Sensor type: Temperature and humidity
- · Humidity Range (%): 15-95
- · RF range (m): >100 in free air
- · RF Frequency (MHz) 868.2
Technical Specifications
Technical Specifications
Sensor (HVAC) | |
| Cable length | - m |
|---|---|
| Max. ambient humidity (non-condensing) | 95 % |
| Number of measuring points | - |
| Diameter sensor element | - mm |
| Housing depth | 34 mm |
| Number of output signals | 0 |
| Sensor length | - mm |
| Housing width | 70 mm |
| Housing height | 70 mm |
| Insert length | - mm |
| Number of output ranges 4 mA ... 20 mA | - |
| Number of output ranges 2 V ... 10 V | - |
| Number of output ranges 0 V ... 5 V | - |
| Number of measuring ranges | - |
| Tolerance | 2 % |
| Number of output ranges 0 mA ... 20 mA | - |
| Number of output ranges 0 V ... 10 V | - |
| Ambient temperature | -10 - 40 °C |
| Rated supply voltage at AC | - - - V |
| Rated supply voltage at DC | - - - V |
| Temperature measuring range | -40 - 125 °C |
| CO2 measuring range | - - - ppm |
| VOC measuring range | - - - ppm |
| Measuring range relative air humidity | 0 - 100 % |
| Measuring range absolute air humidity | - - - g/m³ |
| Enthalpy measuring range | - - - kJ/kg |
| Dewpoint measuring range | - - - % |
| Particulate matter measuring range (PM) | - - - µg/m³ |
| Scope of application, flow speed medium | - - - m/s |
| Compatible with Google Assistant | No |
| Compatible with Apple HomeKit | No |
| Compatible with Amazon Alexa | No |
| Supporting protocol for BACnet | No |
| Suitable for air | Yes |
| Suitable for duct mounting | No |
| Fixed cable to sensor | No |
| Standby push button | No |
|---|---|
| Supporting protocol for MP (multi point) | No |
| Sensor element inside housing | Yes |
| Measurement of dewpoint | No |
| Measurement of CO2 | No |
| Measurement of VOC | No |
| Active temperature measurement | Yes |
| Passive temperature measurement | No |
| Enthalpy measurement | No |
| Particulate matter measurement (PM) | No |
| Measurement of absolute air humidity | No |
| LoRa technology | No |
| With reverse polarity protection | No |
| Offset setting possible | No |
| Potentiometer with adjustment knob | No |
| Sensor element outside housing | No |
| Average temperature measuring | No |
| NFC (Near Field Communication) | No |
| Suitable for wall mounting | Yes |
| Display | No |
| Wireless | Yes |
| Supporting protocol for MODBUS | No |
| Supporting protocol for KNX | No |
| Suitable for ceiling mounting | Yes |
| Bluetooth | No |
| Trend representation | No |
| Suitable for gases | No |
| Suitable for liquids | No |
| IFTTT support available | No |
| Wi-Fi compatible | No |
| Relative air humidity measurement | Yes |
| Error registration possible | No |
| With mounting material | Yes |
| Explosion-proof | No |
| Tube mounting possible | No |
| With housing | Yes |
