Downlight H2 Lite 4000K LED 4.4W Matt White Bezel+Push-Fit
Part Number:
2501013958
MPN:
DLT388MW5540
- Product Type:
- Integrated Residential Downlights
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Manual
Manual
Technical Data Sheet
Product Details
Product Details
A H2 Lite T dimmable, fire-rated LED downlight complete with bezel and terminal connector
- · 100lm/W+
- · Insulation coverable
- · Only 4.4W
- · Uses single point source technology to replicate traditional halogen look
- · Mains dimmable
- · Compact integral driver for easy installation
- · Push-fit terminal connector included
- · LED downlight complete with integrated bezel for a straightforward fit
- · LED downlight complete with integrated bezel for a straightforward fit
- · LED downlight complete with integrated bezel for a straightforward fit
Frequently Bought Together
Current Product
Collingwood Lighting
Downlight H2 Lite 4000K LED 4.4W Matt White Bezel+Push-Fit
Error while fetching price from ERP!
Collingwood Lighting
Downlight H2 Lite 3000K LED 4.4W Matt White Bezel+Push-Fit
Error while fetching price from ERP!
Qty: 1
Collingwood Lighting
Plate Convertor For Halers H2+H4Ff Brushed Steel
Error while fetching price from ERP!
Qty: 1Technical Specifications
Technical Specifications
Downlight / spot luminaire / floodlight | |
| Width | 90 mm |
|---|---|
| Unified Glare Rating (UGR) | 22 |
| Housing colour | White |
| Power factor | 8 |
| Number of lamps | 1 |
| Height/depth | 68 mm |
| Rated life time L70/B50 at 25 °C | 70000 h |
| Maximum system power | 43 W |
| Outer diameter | 90 mm |
| Nominal voltage | 220 - 240 V |
| Colour temperature | 4000 - 4000 K |
| With movement sensor | No |
| Rated ambient temperature acc. IEC62722-2-1 | - 20 °C |
| Light source included | Yes |
| Suitable for suspended mounting | No |
| With light sensor | No |
| Suitable for wall mounting | No |
| Dimming trailing edge | No |
| Suitable for ceiling mounting | Yes |
| Suitable for traverse mounting | No |
| Suitable for pedestal/floor mounting | No |
| Suitable for light-track mounting | No |
| Suitable for clamp-mounting | No |
| Suitable for surface mounting | No |
| Brushed surface | No |
| IFTTT support available | No |
| Fit for workplace acc. EN 12464-1 | No |
|---|---|
| Control gear included | Yes |
| Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24 | No |
| Suitable for recessed mounting | Yes |
| Luminaire may be covered with thermally insulating material | Yes |
| Dimming potentiometer (integrated) | No |
| Dimming sine wave reduction | No |
| Dimming manufacturer's proprietary system | No |
| Dimming DALI-2 | No |
| Suitable for low voltage cable system | No |
| Compatible with Amazon Alexa | No |
| Compatible with Google Assistant | No |
| Dimming leading edge | No |
| Dimming LineSwitch | No |
| Dimming RF | No |
| Dimming Zigbee | No |
| Dimming touch and dim | No |
| Dimming DMX | No |
| Dimming mains voltage modulation | Yes |
| Dimming DSI | No |
| Dimming with push-button | No |
| Compatible with Apple HomeKit | No |
| Dimming programmable | No |
| Dimming DALI | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
