LED Flood light Leo IP66 300W 40000/35000/30000lm 4000K asym
Part Number:
2501496074
MPN:
96635308
- Product Type:
- Commercial & Industrial Floodlights
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
High Power LED Floodlight with asymmetric light distribution, FLEX technology, IP66 for outdoor applications. Luminaire input power: 300 W, Lifetime: 50.000h L80, Total luminous flux: 40000 lm. Luminaire efficacy: 133 lm/W. Colour rendering Ra > 80, colour temperature 4000 K, Chromaticity tolerance (initial MacAdam): 5, Impact strength: IK08. Climate membrane for automatic climate regulation. Surge protection 10kV. Pre-wired with mains cable (1m) including connector for easy and tool-free wiring. Integrated adjustable photocell. Corrosion class C4. Product is not suitable for chlorine environments. Body: die-cast aluminium (<0,1% copper), anthracite grey (RAL 7016), Bracket: steel, anthracite grey. Cover: Tempered glass. Input power adjustable on site by 3 step (FLEX1: 40000 lm (300W), FLEX2: 35000 lm (250W), FLEX3 - 30000 lm (205W)). For flex data on other colour temperatures please visit website. Dimensions: 523 x 634 x 72 mm, weight: 13.1 kg.
- · Rated luminous flux (IEC 62722-2-1): 40000
- · Colour Temperature: 4000
- · Protection Class: I
- · Degree of protection (IP): IP66
Technical Specifications
Technical Specifications
Downlight / spot luminaire / floodlight | |
| Reflector | None |
|---|---|
| Lamp cap/base | None |
| Photobiological safety according to EN 62471 | RG1 |
| Colour rendering index (CRI/Ra) | 80-89 |
| Impact resistance (IK rating) | IK08 |
| Protection class according to IEC 61140 | I |
| Lumen setting adjustable | Discrete positions |
| Colour of light | White |
| Cover material | Glass transparent |
| Filament test according to IEC 60695-2-11 | 650 C - 30 s |
| Control gear | LED driver constant current |
| Colour consistency (McAdam ellipse) | SDCM5 |
| Adjustability | Swivelling |
| Light distribution | Asymmetric |
| Degree of protection (IP), front side | IP66 |
| Colour temperature switchable | No |
| Light outlet | Direct |
| Voltage type | AC |
| Light source type | LED non-replaceable |
| Housing colour | Anthracite |
| Housing material | Aluminium |
| Conductor cross section | - mm² |
| Outer diameter | - mm |
| Length | 523 mm |
| Width | 634 mm |
| Number of poles | - |
| Stroboscope effect value SVM | - |
| Flickering value Pst LM | - |
| Failure rate at median useful life of 35,000 hrs at 25 °C ambient (tq) | - % |
| Unified Glare Rating (UGR) | 33 |
| Lumen maintenance (35,000 h at 25 °C) | 85 % |
| Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq) | - % |
| Height/depth | 72 mm |
| Maximum system power | 300 W |
| Max. number of luminaires per miniature circuit breaker C16 | 9 |
| Lumen maintenance at median useful life of 50,000 hrs at 25 °C ambient (tq) | 80 % |
| Failure rate at median useful life of 50,000 hrs at 25 °C ambient (tq) | - % |
| Max. number of luminaires per miniature circuit breaker B16 | 8 |
| Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq) | - % |
| Number of lamps | 1 |
| Rated life time L70/B50 at 25 °C | 74000 h |
| Power factor | 0.91 |
| Lamp power | - W |
| Colour temperature | 4000 - 4000 K |
| Nominal voltage | 100 - 277 V |
| Connectable conductor cross section | - mm² |
|---|---|
| Rated ambient temperature acc. IEC62722-2-1 | -30 - 50 °C |
| Cut-out diameter | - mm |
| With light sensor | Yes |
| With movement sensor | No |
| IFTTT support available | No |
| Control gear included | Yes |
| Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24 | No |
| Suitable for recessed mounting | No |
| Luminaire may be covered with thermally insulating material | No |
| Suitable for traverse mounting | No |
| Suitable for ceiling mounting | No |
| Light source included | Yes |
| Suitable for suspended mounting | No |
| Suitable for wall mounting | No |
| Fit for workplace acc. EN 12464-1 | No |
| Brushed surface | No |
| Suitable for surface mounting | No |
| Constant luminous flux control | No |
| Dimming 0-10 V | No |
| Suitable for pedestal/floor mounting | No |
| Suitable for light-track mounting | No |
| Suitable for clamp-mounting | No |
| Dimming DALI-2 | No |
| Suitable for low voltage cable system | No |
| Replaceable control gear | No |
| Dimming DSI | No |
| Dimming with push-button | No |
| Compatible with Amazon Alexa | No |
| Compatible with Google Assistant | No |
| Dimming mains voltage modulation | No |
| Dimming trailing edge | No |
| Dimming programmable | No |
| Dimming leading edge | No |
| Dimming DMX | No |
| Dimming DALI | No |
| Dimming manufacturer's proprietary system | No |
| Dimming 1-10 V | No |
| Dimming potentiometer (integrated) | No |
| Compatible with Apple HomeKit | No |
| Dimming RF | No |
| Dimming LineSwitch | No |
| Dimming sine wave reduction | No |
| Dimming Zigbee | No |
| Dimming touch and dim | No |
