Batten LED Slimline IP20 36W 1.2m White 4000K 160°

Part Number:

2500932154

MPN:

RTC364012-01

To view pricing, availability, and special offering, click the button below and log in.

Product Details

TOUCAN 36W LED Batten, IP20, 1.2m, White, 4000K

· Suitable for use in flat and apartment blocks, public buildings, care homes, communal areas, reception areas
· LED replacement for 2x36W T8 fluorescent surface fittings
· Low profile aluminium housing with PBT end caps and polycarbonate diffuser
· High impact rating of IK08
· Complete with stainless steel mounting brackets
· Prewired with 1m of flex
· High efficacy of 106lm/W
· Wide operating ambient temperature range of -20C to +40C
· Suitable for switching by PIR, Microwave or Photocell

Batten luminaire
Degree of protection (IP rating)	IP20
Material	Aluminium
Width	75 mm
Length	1215 mm
Number of poles	-
Number of lamps	-
Luminaire efficacy	106 lm/W
Conductor cross section	- mm²
Rated life time L70/B50 at 25 °C	30000 h
Maximum system power	34.3 W
Height/depth	25 mm
Power factor	0.95
Lamp power	- - - W
Nominal voltage	220 - 240 V
Colour temperature	4000 - 4000 K
Nominal current	160 - 160 mA
Light source included	Yes
With movement sensor	No
Suitable for emergency lighting	No
With light sensor	No
Luminaire with limited surface temperature, class "D“ in acc. with EN 60598-2-24	No


Dimming leading edge	No
Dimming manufacturer's proprietary system	No
Dimming touch and dim	No
Dimming DSI	No
Bluetooth operated	No
Dimming with push-button	No
Dimming Zigbee	No
Dimming RF	No
Dimming DMX	No
Dimming 0-10 V	No
Control gear included	Yes
Dimming trailing edge	No
Luminaire may be covered with thermally insulating material	No
Dimming LineSwitch	No
Dimming DALI	No
Dimming mains voltage modulation	No
Dimming sine wave reduction	No
Dimming potentiometer (integrated)	No
Dimming programmable	No
Dimming 1-10 V	No
