OSRAM DULUX® L LED HF & AC MAINS 24 W/4000K
Part Number:
2501198946
MPN:
4058075559271
- Product Type:
- LED Lamps
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Details
Product Details
DULUX L LED HF 55 840
- · LED replacement for conventional compact fluorescent lamps for use in ECG luminaires or on AC mains
- · Single-ended four-pin plug-in 2G11 base
- · Type of protection: IP20
- · Type of protection: IP20
- · Lifetime: up to 30,000 h
- · Mercury-free lamps
- · Quick, simple and safe replacement
- · Simple replacement thanks to similar design as conventional compact fluorescent lamps
- · Low energy consumption
- · Operation directly on 230 V AC mains possible
Technical Specifications
Technical Specifications
LED Lamp | |
| Lamp shape | Tube, single-ended |
|---|---|
| Colour rendering index (CRI/Ra) | 80-89 |
| Colour | White |
| Housing colour | White |
| Energy efficiency class according to EU regulation 2019/2015 | E |
| Colour consistency (McAdam ellipse) | SDCM6 |
| Cap | 2G11 |
| Photobiological safety according to EN 62471 | RG0 |
| Colour of light acc. EN 12464-1 | Neutral 3300-5300 K |
| Voltage type | AC |
| Type of glass/cover | Frosted |
| Degree of protection (IP rating) | IP20 |
| Luminous intensity | - cd |
| Lamp efficacy | 130 lm/W |
| Diameter | 44 mm |
| Length | 537 mm |
| Weighted energy consumption in 1,000 hours | 25 kWh |
| Average nominal lifespan | 30000 h |
| Power factor | 0.9 |
| Rated luminous flux according to IEC 62612 | 3250 lm |
| Min. number of switching cycles | 200000 |
| Total harmonic distortion | - |
| Nominal current | 110 - 110 mA |
| Luminous flux | 3250 - 3250 lm |
|---|---|
| Beam angle | 140 - 140 ° |
| Nominal voltage | 220 - 220 V |
| Colour temperature | 4000 - 4000 K |
| Lamp power | 25 - 25 W |
| Dimmable | No |
| With remote control | No |
| With movement sensor | No |
| Suitable for electronic ballast | No |
| Remote operation possible | No |
| IFTTT support available | No |
| With twilight switch | No |
| Filament lamp | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Dimming trailing edge | No |
| Dimming leading edge | No |
| Dimming touch and dim | No |
| Dimming Zigbee | No |
| Dimming Bluetooth | No |
| Dimming Wi-Fi | No |
| Suitable for magnetic ballast | No |
