LED AR111 75 24 Degree 11.7W 930 3000K G53 Reflector Lamp
Part Number:
2501594921
MPN:
4099854049040
- Product Type:
- LED Reflectors
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
The Ledvance led ar111 75 24 degree 11.7w 930 3000k g53 reflector lamp is the ideal replacement for your halogen AR111 bulbs. It offers a number of advantages over traditional halogen bulbs.This particular LED AR111 bulb also has a narrow beam angle of 24 degree, making it ideal for spot lighting and accent lighting.
- · Quick, simple and safe replacement without rewiring
- · Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
- · Low maintenance costs thanks to long lifetime
- · No UV and near-IR radiation in the light beam
- · Stepless dimming
- · Very high dimmer compatibility
- · Compatible with many common conventional and electronic control gears
- · Instant 100 % light, no warm-up time
Technical Specifications
Technical Specifications
LED Lamp | |
| Lamp shape | Reflector |
|---|---|
| Cap | G53 |
| Energy efficiency class according to EU regulation 2019/2015 | G |
| Colour consistency (McAdam ellipse) | SDCM4 |
| Lamp designation | AR111 |
| Colour rendering index (CRI/Ra) | 90-100 |
| Colour of light acc. EN 12464-1 | Warm <3300 K |
| Photobiological safety according to EN 62471 | RG1 |
| Degree of protection (IP rating) | IP20 |
| Min. number of switching cycles | 100000 |
| Voltage type | AC/DC |
| Rated luminous flux according to IEC 62612 | 800 lm |
| Diameter | 110.7 mm |
| Luminous intensity | 2800 cd |
| Average nominal lifespan | 40000 h |
| Lamp efficacy | 68 lm/W |
| Weighted energy consumption in 1,000 hours | 12 kWh |
| Power factor | 0.5 |
| Length | 55 mm |
| Nominal voltage | 12 - 12 V |
| Nominal current | 1 - 1 mA |
| Beam angle | 24 - 24 ° |
|---|---|
| Lamp power | 11.7 - 11.7 W |
| Luminous flux | 800 - 800 lm |
| Colour temperature | 3000 - 3000 K |
| IFTTT support available | Yes |
| Suitable for electronic ballast | No |
| With remote control | No |
| With movement sensor | No |
| Compatible with Amazon Alexa | No |
| Suitable for magnetic ballast | No |
| Dimming Bluetooth | No |
| Remote operation possible | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Dimming touch and dim | No |
| Dimming Wi-Fi | No |
| Filament lamp | No |
| Dimming Zigbee | No |
| Dimming leading edge | Yes |
| With twilight switch | No |
| Dimming trailing edge | Yes |
