Tube T5 Triphosphor G5 14W 549mm 830 Sleeved
Part Number:
2500124649
MPN:
4050300591520
- Product Type:
- Fluorescent T5 Lamps
Please Log In
To view pricing, availability, and special offering, click the button below and log in.
Contact our Customer Support Team for assistance on this product
EA
Min: 1 EA
Technical Documents
Technical Documents
Product Documents
Technical Data Sheet
Technical Data Sheet
Product Details
Product Details
The 16mm tubular fluorescent lamp is suitable for public buildings, office lighting, shops, supermarkets, departmental stores and industrial applications. It can also be used in outdoor applications but only in suitable luminaires.
- · Luminous efficacy: up to 104 lm/W
- · Very good lumen maintenance: 90 % throughout the service lifetime of the lamp
- · Good color rendering group: 1B (Ra: 80…89)
- · Good color rendering group: 1B (Ra: 80…89)
- · Dimmable
- · Good economy and efficiency
- · Up to 20 % more economical than LUMILUX® T8
- · Up to 50 % smaller volume than comparable T8 lamps
- · Public buildings
- · Offices
Technical Specifications
Technical Specifications
Fluorescent lamp - tube | |
| Lamp power | 14 W |
|---|---|
| Luminous flux | 1350 lm |
| Beam angle | - ° |
| Colour temperature | 3000 K |
| Weighted energy consumption in 1,000 hours | 14 kWh |
| Average nominal lifespan | 24000 h |
| Colour of light | 830 |
| Lamp efficacy | 96 lm/W |
| Tube diameter | 16 mm |
| Ring diameter | - mm |
| Length | 563.2 mm |
| Ignition strip | No |
|---|---|
| Splitter protection | No |
| Fast ignition | No |
| Starter less operation | No |
| Full spectrum lamp | No |
| Suitable for explosion proof luminaires | No |
| For application at low temperatures | No |
| Internal reflector | No |
| Double-walled | No |
| Suitable for emergency lighting | No |
