Harmony XAP, XB2 SL, Empty control station, zinc alloy, grey, M20, 4 cut-outs 22mm, 80 x 130 x 51,5, UL cULus

Part Number:

2501495934

MPN:

XAPK1201

To view pricing, availability, and special offering, click the button below and log in.

Technical Documents 

Product Documents

Technical Data Sheet



Manual



Product Details

· This product is part of XAP range, an offer of metal control stations for XB4 and XB5 series of Ø 22mm pushbuttons.
· XAPD2204 is an empty enclosure with grey color (RAL7035).
· This version with 4 holes allows combination of XB4/XB5 functions in a small volume. The size remains compact.
· It is possible to customize the XAP with the Harmony online product selector and configurator.
· This product has been standardized with metric thread to be used with ISO cable glands to be fully compliant with the IEC 62444. It comes with two M20 holes.
· The electric shock protection is at class I conforming to EN/IEC 61140 and the mechanical shock protection level is up to IK07 conforming to EN/IEC 62262.
· This is a zinc alloy offer and the dimensions are 80mm (width) x 130mm (height) x 51.5mm (depth) and it weighs 0.600kg.
· XAPD is designed for Original Equipment Manufacturers (OEMs) that meets heavy duty application requirements such as material handling, food & beverage, wind turbines, Mining, Minerals and Metals (MMM), vehicles, etc.
· This enclosure complies with EN/IEC 60529 and EN/IEC 60947-5-1 and comes with CE, UL, cULus and EAC certification.

Enclosure for control circuit devices
Housing material	Zinc
Colour housing cover	Yellow
Degree of protection (IP rating)	IP65/IP67
Construction type housing	Surface mounting housing
Height	80 mm
